Stationary Batching Plant
General Makina gives a new perspective to the ready-made concrete production sector with quality plants and equipment with affordable prices.
Fixed Concrete Plants, which we manufacture, meet the needs of all ready-made concrete companies with different capacities ( small, medium-sized and mega projects)
Diamond 60, Titan 100, Magnum 120 and Royal 150; are our stationary concrete batching plants designed and manufactured to meet the needs of concrete on the job site for years, in harsh climatic conditions, at high performance capacities.
In fixed concrete plants, pan mixer, single shaft or twin shaft concrete mixers can be used as as optional.
Aggregate bunkers can be manufactured with 4 or more chambres. Thanks to the optional aggregate prefeeding unit, it can easily adapt to the layout plan on challenging construction sites and perform as normal.
Cement silos are manufactured welded or bolted in different capacities. Necessary silo equipment; filter, sensor and auger can be added as as optional
All concrete batching plants are equipped with a fully automatic PLC - PC control system..
Control cabin and air conditioner are added as optional.
Our Fixed Concrete Batching Plants produced with ISO 9001 and CE Quality standards and International shipping dimensions.
Manufactured with 45 years of General Makina experience and knowledge.
1 Year warranty excluding wearing parts and use errors.
Local delivery with the necessary operation, maintenance training, and spare parts support for a minimum of 10 years.
You can contact us immediately to meet our affordable Stationary Concrete Batching Plants and to request a detailed offer special for you.
Fixed Concrete Plants, which we manufacture, meet the needs of all ready-made concrete companies with different capacities ( small, medium-sized and mega projects)
Diamond 60, Titan 100, Magnum 120 and Royal 150; are our stationary concrete batching plants designed and manufactured to meet the needs of concrete on the job site for years, in harsh climatic conditions, at high performance capacities.
In fixed concrete plants, pan mixer, single shaft or twin shaft concrete mixers can be used as as optional.
Aggregate bunkers can be manufactured with 4 or more chambres. Thanks to the optional aggregate prefeeding unit, it can easily adapt to the layout plan on challenging construction sites and perform as normal.
Cement silos are manufactured welded or bolted in different capacities. Necessary silo equipment; filter, sensor and auger can be added as as optional
All concrete batching plants are equipped with a fully automatic PLC - PC control system..
Control cabin and air conditioner are added as optional.
Our Fixed Concrete Batching Plants produced with ISO 9001 and CE Quality standards and International shipping dimensions.
Manufactured with 45 years of General Makina experience and knowledge.
1 Year warranty excluding wearing parts and use errors.
Local delivery with the necessary operation, maintenance training, and spare parts support for a minimum of 10 years.
You can contact us immediately to meet our affordable Stationary Concrete Batching Plants and to request a detailed offer special for you.
Model | Diamond 60 | Titan 100 | Magnum 120 | Royal 150 |
Plant Capacity | 55-60m3/s | 100m3/s | 120m3/s | 150m3/s |
Mixer Type | Pan mixser | Twinshaft Mixser | Twinshaft Mixser | Twinshaft Mixser |
Compacted Concrete Mixer | 1m3 | 2m3 | 3m3 | 4m3 |
Dry bulk Mixer | 1.5m3 | 3m3 | 4.5m3 | 6m3 |
Mixser Motor Power | 37kw | 2x45kw | 2x55kw | 2x75kw |
Aggregate Bunker | 4x15m3 | 4x25m3 | 4x30m3 | 4x30m3 |
Aggregate weighing Belt | 800x12000 | 1000x13000 | 1000x14000 | 1000x14600 |
Mixer Feeding Conveyor | 800x27000 | 1000x30000 | 1000x32000 | 1000x32000 |
Aggregate Weighing | 2400kg | 4800kg | 6500kg | 9000kg |
Cement Weighing | 550kg | 1200kg | 1700kg | 2400kg |
Water Weighing | 300lt | 600lt | 1000lt | 1400lt |
Additive Weighing | 25kg | 30kg | 40kg | 50kg |
Cement Screw | Ø219 (Optional) | Ø273 (Optional) | Ø273 (Optional) | Ø323 (Optional) |
Cement Silos (optional) | 60-80-100 ton | 60-80-100 ton | 60-80-100 ton | 60-80-100 ton |
Compressor | 5.5 kw | 7.5kw | 7.5kw | 7.5kw |
